882E 视频HDMI 发生器和分析仪

  • 产品详细
  • 视频
  • 882EA 主要测试项目和功能

    • HDMI 1.4a  , 165Mhz, TMDS 2.25GHz.使用TX: Sil9134 , RX: Sil9135晶片. 完整EIA/CEA-861-D格式支援

    • 類比250Mhz VGA/YPbPr, Composite/S-Video, NTSC/PAL. (881E/882E)

    • Color      depth: 24/30/36 bits 4:4:4 RGB/YCbCr, 16/20/24 bits 4:2:2 YCbCr

    • 支援xvYcc

    • HDMI      Audio: 4 Streams, 8 Channels.內部音源為Sine Wave,可改變音量,頻率,取樣頻率.也可用外部音源.

    • Dolby      Digital, Dolby Digital Plus, Dolby True HD audio.

    • LipSync 測試. Latency讀取、參數修改.

    • HDCP: HDCP      通道功能測試.

    • EDID讀取,編輯,寫入.(882E/882EA).

    • EDID      Format:讀取待測顯示器的EDID      881/882      Format List內自動篩選顯示器所支援之Format,節省測試時間.

    • EDID      Compliance Test (相容性測試): ATC認證推薦(882E/882EA) .

    • CEC      Compliance Test : ATC認證推薦(882EA) .

    • HDCP Compliance      Test(相容性測試):      Source SinkRepeater (882EA) .

    • Image: 點陣圖像支援 BMP, JPG, PNG格式.提供Graphic SDK自建圖像.圖像可以任意方向或速度滾動. 客製圖像可儲存在標準配備為1Gb CF card.

    • ACA(Auxilliary      Channel Analyzer): HDCPEDIDCECDDC通道資料監看,擷取,分析(882E/882EA).

    • InfoFrame:可顯示在待測顯示器的螢幕上或產生報表.

    • Pixel      Repetition:以不同的解析度測試gaming      format.

    • AFD:檢測HDMI視訊內容對應.

    • TMDS電壓可從150-1560mv變化.

    • DVI/HDMI 信號源時序參數, HDMI 纜線Pass/Fail測試,像素RGB/YCbCr讀值量測(882EA)

    882E 主要特点

    Key Features and Benefits

    • 3D Testing per HDMI with 3D Bitmap Conversion Tool

    • Image Control Tool to fine tune deep color images (882E only).

    • DTV ready–Pre-programmed standard DTV formats are ready for immediate use. Digital outputs support YCbCr color encoding. Analog outputs support tri-level composite sync and YPbPr.

    • Built-in formats–Over 350 popular video formats are built-in including VESA, ATSC, EIA-770.x, SMPTE 170, 240, 259, 267, 274, 292, 293, 295, 296, Australian, EIA/CEA-861D, NTSC and PAL.

    • Central administration–Update and configure all networked instruments from a single computer.

    • Network control–Fully control instrument from any network location with web browser or Telnet client.

    • Graphics SDK–Create complex patterns based on your specifications using C++ software development kit.

    • HDMI–Full single-link HDMI. DVI HDCP production keys for HDMI output.

    • Easy to use–Access powerful features easily using intuitive user interface.

    • Multiple configurations–Save and restore different instrument configurations for different applications.

    • Local pattern storage–Store multiple custom images (.bmp, .jpg, and .png) images in instrument.

    • Self-calibrating–Analog video outputs are automatically adjusted against an internal precision reference. This assures video levels that are precise and reliable. Signal levels are auto-adjusted individually.

    • Probe–Trigger a scope or inspection camera using the probe signal. Position a pulse anywhere in the frame.

    • PC Card–Clone one generator to another using a standard CompactFlash card.

    • Auxiliary Channel Analyzer (ACA)–The ACA enables you to monitor DDC, HDCP, CEC and EDID transactions for HDMI and HDCP, Link Layer and EDID transactions over the DisplayPort auxiliary channels.

    • IEEE-488-GPIB (IEEE-488) interface. interface.

    • RS-232-Industry standard serial interface.

     Options

    For the 882E one of the two following digital options must be selected:

    • HDMI Transmitter:

      • Advanced E-EDID parsing

      • 3D Pattern Testing for HDMI formats

      • Deep Color at 24/30/36-bit/pixel 4:4:4 RGB / YCbCr

      • 16/20/24-bit/pixel 4:2:2 YCbCr

      • High-level Active Format Description (AFD) controls

      • AFD test suite

      • Pixel repetition test suite

      • Automatic and manual InfoFrame setup

      • Compressed Dolby Digital formats (Plus & TrueHD)

      • Internal sine wave generator (LPCM), and external SPDIF audio input

      • 32, 44.1, 48, 88.2, 176.4 and 192kHz audio sampling rates

      • Generates all EIA/CEA-861D formats below 165 MHz, with all possible variations

      • Complete letterbox and scope coverage

      • 4:2:2 color sub-sampling at 8, 10, and 12-bits per component

      • Hot-plug format list

      • Includes DVI-D (M) to HDMI (M) cable and HDMI-HDMI cable.

    • DisplayPort Transmitter:

      • Link layer testing (compliance and monitoring)

      • HDCP compliance testing of sink devices

      • Pixel rates up to 268MHz

      • 1, 2 & 4 lanes user selectable

      • 1.62GB/s and 2.7Gb/s per lane rate user selectable

      • 4:4:4 color sub-sampling

      • 6, 8, and 10-bits per component

      • RGB and YCbCr colorimetry

      • Hot-plug format list

      • Includes DisplayPort cable.

    • Analog Video component and composite (882E HDMI only)

      • Component analog up to 250MHz

      • Component analog VGA Connector

      • Composite analog on S-video and BNC Connectors

    For the 882E one of the two following analyzer options can be selected:

    • HDMI Analyzer available with HDMI Tx on 882E only

      • Dual HDMI Tx and dual HDMI Rx ports

      • Supports full single-link HDMI (with deep color) and DVI analyzer up to (150MHz) in same instrument.

      • Measure source timing and source pixel errors. Also useful for testing cables. Test results can be issued as formatted reports.

      • Emulate EDIDs.

    • DisplayPort Analyzer available with DisplayPort Tx on 882E only

      • Provides monitoring of auxiliary channel such as EDID, HDCP and link layer transactions through internal connector.

      • Supports link layer compliance testing for DisplayPort source devices in addition to DisplayPort sink devices.

      • Emulate VESA EDIDs.

      • Single DisplayPort Tx and Single DisplayPort Rx ports

    For the 882E HDMI, the following options are available:

    • Options with the 882E HDMI

      • CEC Integrated Troubleshooting Environment (ITE)

    • Options with the 882E HDMI Analyzer

      • CEC Integrated Troubleshooting Environment (ITE) - Debug environment

      • CEC Test Management Environment (TME) - HDMI CEC compliance (approved by HDMI)

      • HDCP compliance test - HDMI HDCP CTS 1.2

    For the 882E DisplayPort, the following options are available:

    • Options with the 882E DisplayPort

      • VESA EDID 1.4 Verification Test

    • Options with the 882E DisplayPort Analyzer

      • HDCP compliance test for DisplayPort sink devices

      • Link Layer compliance test for DisplayPort sink devices (VESA approved)

      • Link Layer compliance test for DisplayPort sink & source devices (VESA approved)

      • Auxiliary Channel Analzyer (ACA)

      • VESA EDID 1.4 Verification Test

     Cables

    • Null Modem (p/n 30-00124)–The null modem cable is provide with all 880 series generators. It is used for connecting a PC to the generator to control the generator through the command line interface.

    • Ethernet cross over cable (p/n 30-00151)–The Ethernet cross over cable is provide with all 880 series generators. It is used for connecting a PC to the generator for web browser access.

    • Line Cord (p/n 30A00400A03)–The 6 foot line cord is provided with all 880 series generators. It is a detachable power cord used to provide power to the generator.

    • BNC to RCA adaptor (p/n 30-00123)–The BNC to RCA adaptor is provided with 880 series generators. It is used on the TV to allow a coaxial cable connection from the TV to the generator's BNC TV output.

    • DVI to HDMI adaptor (p/n 30-00145)–The 6 foot DVI to HDMI cable is provided with 880 series generators. It is used to connect the generator to a DVI monitor from the generator's HDMI output connector.

    • HDMI to HDMI cable (p/n 30-00146)–The 6 foot HDMI to HDMI cable is provided with 880 series generators. It is used to connect the generator to an HDMI monitor from the generator's HDMI output connector.

    • DisplayPort to DisplayPort cable (p/n 30-00162)–The 6 foot DisplayPort to DisplayPort cable is provided with 880 series generators. It is used to connect the generator to a DisplayPort monitor or transmitter from one of the 882E DisplayPort connectors.

     Accessories

    • ESD-1 (00-00167). Provides external ESD protection for DVI connectors.

    • 128MB Compact flash memory card (82-00133 and 82-00134)

    • Remote keypad (00-00123) Allow entry of numeric command to load images and formats from up to 43" (1.1 m) from the generator.
